Home-Computer Light Guns

Before the console guns, the light pen.

Light pens and light guns for the Atari 8-bit, Apple II, PET, C64, Spectrum, MSX and more, down to the port pin.

Photo: Magnum Light Phaser (Sinclair-branded, for the ZX Spectrum) by Boffy b · CC BY 2.5

Search every volume:

?

How to search

sten gun
pages with both words
"sten gun"
the words together, as a phrase
sten OR sterling
either one (| works too)
sten -replica
leave out pages that mention “replica”

Without quotes, the last word also matches longer words that start with it (sten finds Stenophylla), and close word forms count (rifle finds rifles). Tick Exact words to match whole words only.

Whole deep dives are listed first, then the pages inside them.

    Volumes

    1. Vol 1 The Light Pen — From SAGE to the Home Computer Why a pen on a 1950s air-defence console needed no position hardware, why a pen on a television did, and why the home computers that built that hardware into their video chips had light guns before most consoles
    2. Vol 2 Atari 400/800, XL, XE and the XE Game System ANTIC's light-pen latch on the joystick trigger line, Atari's own light pens, and the XG-1 light gun as a computer peripheral: pins, registers, software and games
    3. Vol 3 Commodore — PET, VIC-20, C64 and C128, Amiga Pin 6 of the game port and the VIC and VIC-II light-pen registers; why a C64 gun from one maker so often fails with another maker's games; the Defender 64 and the Light Fantastic pack; and the Amiga's beam trigger
    4. Vol 4 Sinclair and Amstrad — the Spectrum, the CPC, the Plus Range and GX4000 A computer with no latch at all and the guns that worked round it through a tape socket, a sound chip's port and the joystick interface; the CPC's 6845 on pin 47 of the expansion connector; and the Trojan Phazer on the Plus range
    5. Vol 5 BBC Micro, MSX, Apple II, Thomson and the Atari STE The BBC's 6845 light-pen strobe on pin 9 of the analogue port and the arithmetic that turns its address into a position; MSX1 with no latch and MSX2's V9938 with one; the Apple II's pens on their own cards; the French computers that shipped with a pen; and Atari's last light-gun port
    6. Vol 6 Side by Side, and Using One Today Seven latch formats compared; calibration, dark targets and averaging as each maker described them; why one maker's gun so rarely worked with another's games; and what it takes to run, emulate or bench-test a home-computer gun now
